Feller Buncher Head

Name: Feller Buncher Head
Brand: YANTAI SC EQUIPMENT CO.,LTD.
Availability: InStock

The feller buncher head for excavators is a highly efficient forestry attachment that integrates tree cutting, gripping, and bunching into one operation. Powered by a hydraulic system, it delivers fast cutting speed and strong stability, enabling flexible performance in complex terrains. Compared to traditional manual or single-function equipment, it significantly improves efficiency while reducing labor costs. The structure is durable and relatively easy to maintain, making it suitable for various working conditions. The maximum cutting diameter reaches 500–850 mm. It can meet the needs of harvesting medium to large trees, making it an ideal solution for modern forestry and land clearing operations.

Inquiry

Features Specification Images Video

Features of Feller Buncher Head

The maximum cutting diameter reaches 500–850 mm.
Compatible with 20-60 ton excavators, making it a cost-effective alternative to dedicated forestry machines.
Suitable for tough terrain conditions, and situations Integrates cutting, gripping, and bunching into one operation, greatly improving work efficiency.
Hydraulic drive system ensures fast cutting speed and stable performance.
360° rotation offering strong precision and flexibility.
Reduces labor requirements and lowers overall operating costs.
Durable structure with low maintenance needs for long-term use.

Specification of Feller Buncher Head

Model	SC20	SC35
Excavator weight	20-35T	35-50T
Height A	1950mm	2625mm
Width B	1760mm	1900mm
Depth C	1700mm	1800mm
Front opening	1460mm	1550mm
Weight(no rotate)	1900kg	2800kg
Weight(with rotate)	2450kg	3350kg
Singel cut diameter	500mm	650mm
Dual cut diameter	850mm	950mm
Accumulating area	0.56m³	0.7m³
Accumulating capacity	7-9trees 150mm diameter	8-10trees 150mm diameter
Oil pressure	20-30MPa	20-30MPa
Oil flow	160-220L/min	160-220L/min
Disc diameter	1530mm	1690mm
Teeth	18 pcs, Carbide or hardened steel	18 pcs, Carbide or hardened steel
Motor capacity	160ml/r	160ml/r
Blade speed	1000-1400r/min	1000-1400r/min
Saw drive	Direct drive; Piston motor	Direct drive; Piston motor
